Hi All,

Today we will discuss how to upgrade a vSphere Distributed switch 5.5 to 6.0.

The upgrade of a distributed switch is a non disruptive operation, that is, the hosts and virtual machines attached to the switch do not experience any downtime.

Before proceeding the upgradation for best practice I am going to export my vDS 5.5 configuration files.

Right click on vDS 5.5, go to settings and select Export Configuration…

Desktop-1-2016-06-13-01-07-11

Select “Distributed switch and all port groups” option, Click OK.

Desktop-1-2016-06-13-01-08-48

Once the configuration file exported, Select “Yes” to save in your local desktop.

Desktop-1-2016-06-13-01-09-07

In the below screenshot, current vDS version is 5.5.0 I am going to upgrade to 6.0.0

Desktop-1-2016-06-13-01-11-07

Right click on vDS 5.5 and navigate to upgrade, Select “Upgrade Distributed Switch” option.

Desktop-1-2016-06-13-01-12-45

Click “Next” to continue:-

Desktop-1-2016-06-13-01-12-52

Check host comparability and click “Next”

Desktop-1-2016-06-13-01-14-31

” Once upgraded the distributed switch cannot be downgraded to a previous distributed version. You will not be able to add older VMware ESX Server members that are not compatible with the new distributed switch”

Click on “Finish” button.



Desktop-1-2016-06-13-01-17-44

Verify vDS is upgraded to 6.0.0

Desktop-1-2016-06-13-01-17-54

Thanks for reading, If you like the post share to others!!!!
